PP knitted wire mesh is produced by special machines by knitting weave process with polypropylene (PP) or polythene (PE) that the non-metal wire as raw material, knitted into a seamless and continuous tubular form. PP knitted wire mesh is most commonly used in filtration and separation applications, such as demister pads and coalescers (reactor internals).

WEB WIRE MESH can offer PP knitted wire mesh in the standard specifications, opening sizes range from 1 mmx 1 mm to 5 mm x 5 mm, while wire diameters range from 0.15 mm to 0.28 mm. Depending on the specification, the manufactured widths are between 100 mm and 600 mm. The standard material is PP wire.

Benefits

Soft, non-sparking, nonmagnetic and rust free

Greater corrosion resistance

Light weight and high strength

High filtering performance

Durable and long service life

PP knitted wire mesh materials

PP knitted wire mesh is available in two types different wire materials:

Plastic and fiber: polypropylene (PP), polythene (PE)

Others available, please ask

Application

Usage of PP knitted wire mesh includes:

In the filtration & separation industries, for the screen of the fiber bed mist eliminator (Candle filter).

PP knitted wire mesh rolls

Roll width 100 mm, 200 mm to 600 mm (measured on flat)

Roll length 15 m, 30 m, 50 m to 100 m

Other rolls size on request

Weave type

Technical parameter

PP knitted wire mesh data sheets

When ordering or requesting a quote for PP knitted wire mesh, please specify:

Number of length 30 m rolls or size required

Width eg. 200 mm

Diameter of wire eg. 0.21 mm

Aperture eg. 3 mm x 5 mm

Material eg. polypropylene (PP)

Standard & Compare
